Features

• Our Italian Industry series has loads of configurations to suit every need
• Fully manufactured in Italy
• Stainless swivel
• CO Plate included
• The hose must be fully retracted when the reel is in use
• * After fitting the hose, turn the spring this many times to charge the spring. Do not turn more as you will jam the spring
• HOSE NOT INCLUDED
• Choose the BK style for braked version

Specifications

• Reel Style: Standard Bent Arm
• Capacity:
  • 20 m of 1/4” hose
  • 20 m of 3/8” hose
  • 20 m of 1/2” hose
• Pressure: 5,800 PSI
• Inlet/Outlet: 3/8” F BSP x 1/2” M BSP
• Temperature: 90°C
• Material: Stainless
• Spring Turns*: 2
• Dimensions: H 21 x W 56 x D 43

Connection Options

***New Series from 2023 June: HR1100 3/8 400 HAI
