Features
For accurate, repeatable by-pass regulation wherever absolute reliability in pump output control is necessary. Continually regulates pressure within 5% of setting. Can be set up to both regulate and absorb normal pulsation thus eliminating the need for a pulsation dampener. Can be parallel mounted. Responds in .004 seconds or less. Designed for Weep Systems.
- Body and Stem; Steel, Electroless Nickel plated.
- 416SST hardened stainless steel Piston Cap & Inlet Cap.
- Spring steel Springs.
- Viton® Seals.
- Requires 5% minimum by-pass.
- Not recommended for use with single or two cylinder pumps.
Specifications
- Body Material: Nickel-Plated Steel
- Port Size A: 3/8″
- Port Type A: FPT
- Max Pressure: 1,000 PSI
- Maximum Temperature: 120 °C
- Manufacturer Part Number: BR5-1
