Open Top Cleaning Head

SKU: 145 25.6000.10

Flow 100 L/min – 26,45 USGpm
Stainless Steel 303
NPT Nozzle Ports (Nozzles not Included)

POA

Compare

Mosmatic Open Top Cleaning Head – Self-Propelling

These high quality, Italian made cleaning heads are the ideal choice for cleaning closed containers.

Specifications

  • 1,015 PSI Rated Pressure
  • 435 – 1,015 PSI Total Pressure Range
  • 100 L/min Flow Rate Range
  • 90°C Max Temperature Rating
  • 360° Spray Coverage
  • 183 mm () Minimum Barrel Diameter
  • 1-1/4″ BSP Female Inlet Port
  • (4) 1/4″ NPT Nozzle Ports (Nozzles not Included)
  • 4-5 Giri/min Rated RPM
  • 10.2 kg Unit Weight
  • 303 Stainless Construction

Range Review

Part NumberFlowNozzle TypeMin.overall ØWeight
145 25.6000.10100 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz
145 25.6000.15130 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz
145 25.6000.17150 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz
145 25.6000.20180 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz
145 25.6000.24220 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz
145 25.6000.30300 L/min4 × 1/4 NPT183 mm – 7,19″10,200 gr / 360 oz

*Nozzles Not Included
Once Cleaning Head is Selected, Fill Out Specifications Sheet and Submit to BAR for Confirmation.
