Pratissoli KThp Plunger Pump

Construction

• Triplex plunger pump, available in 4 versions.
• Patent pending, symmetrical power end design featuring top and bottom mounting holes allowing for easy left-to-right shaft conversion.
• Pressure packing design with integrated cooling system
• Vertically fitted valves.
• Splash lubrication.

Features

• High-resistance light alloy crankcase.
• Stainless steel manifold, nickel treated.
• Tapered roller rim bearings.
• Special antifriction light alloy con rods.
• Forged alloy steel crankshaft, hardened, tempered and nitrited.
• Cast iron piston guide, nickel treated.
• Solid ceramic plungers.
• Stainless steel valves.

Specifications

• Pressure: 5800Psi
• Flow: 36 L/min
• Speed: 1750Rpm
• HP / kW 38/27.9
