Features

• M22 Coupling
• AR1 “A” Type
• 3 Piece Non Rotating Pin
• Select 145 26.0250.20 or 145 26.0250.40 for vacuum excavation industry applications

Specifications

• Inlet: Variable
• Outlet: M22 x 1.5 Male Standard 14 mm Pin
• Working Flow: 40 L/min
• Working Pressure: 3,650 psi
• Maximum Pressure: 4,050 psi
• Working Temperature: 160°C
• Material: Brass (or Stainless 303 for 145 26.0235.51 and 145 26.0230.40)
