Features

• With the KDI diesel engine, we started from scratch to build an entirely new engine experience. Using state-of the-art technology to control the combustion process, we created a diesel that delivers more power and more torque in a smaller frame. So you can keep your performance and downsize your engine.
• One engine platform for the entire world
• Smart emission management system
• Excellent fuel efficiency
• Long service intervals
• Low noise, low vibration

Equipment types

This engine powers the following equipments

• 4WD Tractor
• Aerial Platform
• Air Compressor
• Asphalt Cutter
• Compact Shovel Loader
• Compaction Roller
• Concrete Sprayer
• Dumper
• Excavator
• Firefighting Pump
• Forklift
• Fruit Yard/Vineyard Tractor
• Generator Set
• Motor Sweeper
• Pressure Washer
• Refrigeration Unit
• Self-Priming Water Pump
• Skid Steer Loader
• Stringing Equipment
• Water Pump (Irrigation)
• Welder
• Wheeled Loader

Specifications

• Power kW (hp): 31 (42) @ 2,600 RPM
• Displacement: 1,861 cm3
• Bore: 88 mm
• Stroke: 4 mm
• Maximum Torque – Nm (lb-ft): 133 (98.1) @ 1,500 RPM
• Dry Weight: 210 kg
• Oil Capacity: 8.5 L
• Engine Type: Commercial
• Compression Ratio: N/A
• Lubrication: Full pressure w/full-flow filter
• Dimensions: L 598 mm x W 452 mm x H 667 mm
