Features

Exceptional power. That’s what you’re getting with liquid-cooled diesel engines! Fast-acting fuel injection technology delivers the punch you need and fuel savings you expect.  And our belt-driven, overhead camshaft delivers low-turbulence performance for near-silent operation.

• Integrated fuel-injection system and overhead cam help ensure less maintenance and fewer trips to the shop
• Superior balance, lower cylinder volume, and belt-driven valve train provide nearly non-existent noise and smooth operation
• Cast-iron block construction ensures durability and lasting performance
• 3-year limited warranty

Engine Type

• Four-stroke in-line, cast iron block, aluminum cylinder head, indirect injection with injector pump on head

Specifications

• Model: KDW1003
• Power: 17.7 kW (23.7 HP) @ 3,600 RPM
• Displacement: 1,028 cm3 (62.7 in3)
• Bore: 75 mm (3″)
• Stroke: 77.6 mm (3.1″)
• Maximum Torque: 50 Nm (36.8) @ 2,600 RPM
• Dry Weight: 85 kg
• Oil Capacity: 2.4 L
• Engine Type: Commercial
• Compression Ratio: 22.8:1
• Lubrication: Full pressure w/full-flow filter
• Dimensions: L 516 mm x W 412 mm x H 519 mm

Notes

• 1 Performances measured according to ISO 14396 without final intake and exhaust line.

• Actual engine performances may be affected by accessories (intake and exhaust line, charging , cooling fan, etc.), application, ambient operating conditions (temperature, humidity and altitute) and other factors.
