Features

• Pump comes with bypass valve, safety valves, and pressure switch
• Thermostat for Temperature Adjustment
• Stainless steel vertical wrap boiler and cover
• Heat ventilation by independent electric motor
• 24 V Low Tension Electrical Controls
• Steam Valve
• Stainless Water Break Tank
• High Pressure Detergent Injection
• Low level fuel cut-out with burner stop
• Fuel Tank capacity at 32 Litres
• Painted steel frame with stainless steel cover
• High efficiency vertical AVANT XL boiler with stainless steel body
• Heat ventilation by independent electric motor
• Professional pump with ceramic plungers
• Bypass valve
• Safety valve
• Burner control with flow switch and pressure switch
• Flame control with photocell
• Stainless steel water tank
• Pump motor coupling with elastic joint
• Water level control (machine stop in case of lack of water).
• Adjustable high pressure chemical suction.
• Anti-scale system
• External tap for pressure and chemical regulation.
• 24 V Low tension electrical controls.
• Magneto thermic overload switch.
• Total Stop with Time Delay shut off (after 1 hour)
• Made in Italy

Specifications

• Pressure: 2,000 PSI
• Flow: 21 L/min
• Pump: Interpump Italy Triplex Piston Pump WS201
• Speed: 1,440 RPM
• Motor: Nicolini Electric 415 V
• Power: 5.5 Kw / 7.5 Hp
• Max Temperature: 100°C
• Frame:
  • AISI 304 Stainless Steel Casing
  • Stainless Steel Coil
  • Painted Steel Frame
• Weight: 150 Kg

Standard Accessories

• 10 m HP hose with quick coupling
• 120 cm lance
• Professional gun
• Stainless steel water nozzle

Optional Accessories

• Electric antiscale
• Stainless steel coil
•  Damper
• Water level control – machine stop in case of lack of water
• Stainless steel cover
• Wheel with brake
• Sandblasting head
• Rotating nozzle
• Drain pipe kit

Äbout the manufacturer, MAER
