Specifications

• Engine Type: 4-stroke 2-cylinder, OHV PETROL ENGINE, horizontal shaft
• Fuel system: Electronic fuel injection
• Cylinder sleeve type: Cast iron sleeve
• Bore x stroke: 2 / 83 x 72
• Displacement: 779 cm³
• Compression ratio: 9.1
• Net power: 18.5kW (24.8Hp) / 3600Rpm
• Cont. rated power: 13.3 kW (17.8Hp) / 3000rpm     15.0kW(20.1Hp) / 3600 rpm
• Ignition system: Full-transistor Ignition Coil
• Max.net torque: 48.3 Nm / 4.93 kgfm / 2500 rpm
• Lubrication: Full-pressure
• Starting system: Electric starter
• Engine oil capacity: 2.1L
• Dey weight: 48.2kg

iGX700/iGX800 TXR engines can be activated by connecting the Y/B (sw1) wire & G(F):SGND (Green circle below)
