Specifications

• Maximum pressure: 170 Bar
• Maximum Flow: 40 – 48 L/min
• Input connection: G. 3/4 ″ H
• Output Connection: G. 1/2 ″ H
• Weight: 17.2 Kg.
• Dimensions: L 341.5 mm x H 168.2 mm x W 263 mm
• Material: Brass stock.
• Power: 17 CV-12.6 KW (50Hz) -20.4 CV-15.3 KW (60Hz).
• Speed: 1,450 RPM (50Hz) – 1740 RPM (60Hz).
• Axis: 24 mm- right (optional 25 mm axle)
