“C” Series Hand Crank Reel

ReCoila C Series steel hose reels utilise the basic design from our popular T series range, whilst offering an economical price. A basic but practical hand operated design makes the C series ideally suited to a variety of applications. This simple but tough hose reel will handle a multitude of hose sizes, lengths and pressures. The main axle is supported by ball bearings, offering a smooth and reliable rotation, while the adjustable friction brake allows the user to add or remove drag to prevent over spooling. The positive lock spool-lock holds the spool fixed during transit, preventing overrun, and the open spool design allows air flow to help dry out wet areas. A bolt together frame and spool offers easy access for maintenance and service. The unique modular design of the C series also allows the user to add or change drive systems in the field or at a later date with a simple bolt-on feature.

Specifications

• Series: C
• ID: 10 mm
• Length: 40 m
• Pressure: 5,000 PSI
• Rewind Type: Manual
• Inlet Fitting: 1/2″
• Outlet Fitting: 1/2″
• Max Temp: 95°C
• Finish: Steel, 304 Stainless Steel, 316 Stainless Steel
• Seal Material: Aflas
• Hose Inclusion: No
