Pump Specs
- GPM: 3.2
- PSI: 10,000
- RPM: 1,450
- Shaft Diameter: 30 mm
- Piston Diameter: 15 mm
Pump Features
- 1/2″ FPT Inlet, 1/2″ FPT Outlet (Female degree cone seat)
- Solid Shaft 30mm for Belt Drive, Gearbox or Flex Couplers
- Right or Left Hand Mounting Available Crankcase: Die-Case Aluminum Alloy for Protection Against Corrosion
- Top-Quality and oversized conical Roller Bearings with covers for adjusting the pre-load
- Piston Guides are Heat Treated Stainless Steel
- Highly Efficient Stainless Steel Check Valves
- Large Oil Capacity Dissipates Heat and Improves Lubrication for Longer Life
- Plungers with Tungsten carbide coating, higly corrosion and abrasion-proof
- Heavy Duty up to 11,600 psi
- Stainless Steel Manifolds
- High Volume up to 3.6 GPM
- Special Aluminum Alloy Conrods made in a double piece
- Long Life Seals
Code | Type | RPM | Flow rate | Pressure | Power | Weight | ||
|---|---|---|---|---|---|---|---|---|
l/min | bar | psi | hp | kW | kg | |||
| 210 TW35100S | 1,450 | 14.6 | 700 | 10,153 | 24.4 | 17.9 | 34.5 | |
| 210 TW40100S | 1,450 | 16.1 | 700 | 10,153 | 26.9 | 19.8 | 34.5 | |
Head material legend
Stainless Steel
