Features

Diaphragm technology extends the life of the diaphragms by shielding them from direct contact with the chemical inlet. This spreads inlet vacuum often caused by a dirty suction filter or kinked hose, across the entire surface of the diaphragm instead of focusing it on one small area where most failures occur.

• Chemical resistant wet parts
• Compatible with aggressive soft wash chemicals
• Hexagonal manifolds for smooth and quiet operation
• Fits standard engines with 3/4″ keyed shaft
• Injection molded plastic parts with UV stabilization
• Secure bracket system to prevent manifold leaks
• Triple Diaphragm
• Add:
  • Gear Box – 115 50050240
  • Regulator Valve – 115 12040662

Specifications

• Speed: 550 RPM
• Pressure: 145 PSI
• Flow: 35 L/min
• Engine – Power: 0.9 HP
• Weight: 25.6 lbs
