Features
- Semi-Hydraulic, Four Diaphragm Pump
- Tackles Fluid Transfer Applications up to 725 PSI and 24.7 GPM
- Features Brass Heads and Brass External Manifolds to Provide Corrosion Resistance
- Perfect for High Pressure Agricultural and Horticultural Applications Such as Orchards, Vegetables, Trees, Vineyard Spraying, and More
- Easily Connects to Tractor PTOs with the 6 Spline PTO Shaft (1 3/8″) Setup
- Self-Priming, Large Capacity Oil Bath Crankcase, Mounting Rails and Can be Run Dry
- Operates at Maximum of 550 RPMs and 11.5 HP
- 1 Year Warranty on Manufacturer Defects
Specifications
- # of Diaphragms: 4
- Max Pressure: 725 PSI
- Max Flow: 92 L/min (24.5 GPM)
- Max Speed: 550 RPM
- Suction Diameter: Ø 40mm
- Delivery Diameter: G 3/4″ F, Ø 10mm (x2)
- Pump: Brass
- Diaphragm/Seal Material: Buna
- Oil Capacity: 37.2 fl oz
- Weight: 66.6 lbs
