TOUGH, RELIABLE, EFFICIENT
- Engineered for durability and performance, the 16HP Vanguard engine is built to power through the most demanding commercial applications with ease. With its energetic, quick-starting design and a suite of advanced technologies, this engine sets a new standard for reliability. Integrated components enhance operational efficiency, helping professionals get more done in less time.
Typical Applications
- Golf and turf equipment, Utility vehicles, Commercial mowers, Power packs
- Whether you’re maintaining landscapes or managing large-scale operations, this Vanguard engine delivers the dependable power you can count on.
Specifications
- Gross Horsepower: 16
- Engine Displacement (cc): 479 cc (29.23 cu in)
- Number of Cylinders: Two
- Engine Configuration: Horizontal
- Bore: 2.68in (68mm)
- Stroke: 2.60in (66mm)
- Compression Ratio: 8.2
- Ignition System: Magnetron®
- Lubrication System: Full Pressure w/ Spin On Oil Filter
- Carburetor: Single Barrel Float Feed
- Engine Cooling: Air
- Engine Fuel: Gasoline or Gaseous
- Governor: Mechanical
- PTO (Standard): 1″ SAE Keyway (See Options Tab)
- Cylinder Block: Aluminum Alloy with Dura-Bore Cast Iron Sleeve
- Crankshaft: Ductile Iron
- PTO Shaft Rotation: Counterclockwise from PTO Side
- Starter: Electric
- EPA Compliant Engine: Yes
- Length x Width x Height: 10.98in (279mm) x 16.14in (410mm) x 17.24in (438mm)
- Weight: 72lbs (32.7kg)
- Oil Capacity: 57.5oz (1.7L)
- Engine Displacement (cc): 479 cc (29.23 cu in)
