XWL41.20 Annovi Reverberi 24mm Solid Shaft Pump – 2,900 PSI – 1,450 RPM – 41 L/min
Features
- The XWL41.20 Annovi Reverberi (AR) has a 24mm solid shaft pump & offers a massive 41 litres flow rate, 200 bar or 2900PSI and runs at 1450RPM. You will need a 20HP motor to run at full pressure. A benefit of this pump is that it can be fitted to various motor types, either directly or via a flexible joint.
- Can be coupled to various types of motors, directly or with flexible joint.
- Pump body and cover in die-cast aluminium alloy.
- Side cover may be blind or incorporate oil sight glass.
- Rear cover with oil drain outlet and sight glass.
- Pistons are driven by crank-connecting rod mechanism.
- Pump shaft in pressed high-strength steel.
- Oversized friction bearings.
- 1450 RPM ideal to be driven by electrical motors. 24mm Solid Shaft.
- 20 HP required to run at full pressure
- 3-piston alternating volumetric pumps for use on cleaning units and industrial systems.
Specifications
- Pressure: 2,900 PSI
- Flow: 41 L/min
- Inlet: 3/4″ BSP F
- Outlet: 3/8″ BSP F
- Weight: 15.8 kg
