Features

• Nickel-Plated brass body with rotating front gaskets in high resistance ceramic material. The rotation is based upon two stainless steel ball bearings protected against water leaks for long life span.

Specifications

• Rated Pressure: 350 bar – 35 MPa – 5,100 PSI
• Permissible Pressure: 390 bar – 39 MPa – 5,650 PSI
• Rated Flow Rate: 40 L/min – 10,5 USGpm
• Rated Temperature: 120 °C – 250 °F
• Max Working Temp: 90 °C – 194 °F
• Max Speed: 2000 giri/min
• Material: Stainless Steel + nick.pl. brass
